Jackery SolarSaga 500X Solar Panel

DESCRIPTION

The Jackery SolarSaga 500X is a high-output folding solar system for compatible Jackery power stations. Six independently operating 85W panel sections provide up to 500W of rated power while allowing flexible deployment around partial shade and limited space.

• Returns are subject to The YardSpace Co. Return Policy and applicable manufacturer or distributor restrictions. Return shipping may be the customer’s responsibility unless the vendor’s policy provides otherwise.

KEY FEATURES

• 500W rated output from six 85W panel sections.
• TOPCon bifacial cells with up to 25% conversion efficiency.
• IP68-rated protection against water and dust when connections are used as directed.
• Operating range from approximately -40°F to 185°F.
• Foldable, modular design for temporary ground, balcony or rooftop placement.
• Parallel-only electrical configuration; do not connect panel sections in series.

SPECIFICATIONS

• Rated output: 500W system
• Panel layout: Six independent 85W sections
• Cell technology: TOPCon bifacial
• Maximum conversion efficiency: 25%
• Ingress rating: IP68
• Operating temperature: Approximately -40°F to 185°F
• Connection: Parallel only; maximum six panels per compatible DC8020 input port
• Installation: Portable/temporary deployment; not intended as a permanent fixed installation

WHAT’S INCLUDED

• SolarSaga 500X folding panel system
• Compatible connection hardware supplied by Jackery
• Manufacturer documentation
